Chapter 4
Configuring Your Decoder
4–14
Figure 4.1 shows the first setup screen. The first setup screen configures the
communication parameters and host protocol. We have used lowercase
letters to indicate fields of the configuration data. These letters are keyed to
Table 4.C, listing the options available for each field type. Following the
table is a short description of the effect each option has on the decoder
operation.
----------- MESSAGE FORMAT ----------- ----------- HOST COMM -----------
SEND BAR CODE DATA: a BAUD RATE: u
SEND PACKAGE COUNT: b BITS/CHAR: v
SEND BAR CODE TYPE:
c
PARITY: w
SEND SOURCE IDENTIFIER: d
SEND HEADER MESSAGE: e ACK CHAR: x
SEND NO-READ MESSAGE: f NAK CHAR: y
START SCAN CHAR: z
EXPAND UPC-E: g STOP SCAN CHAR: aa
SOURCE IDENTIFIER: h LARGE BUFFER: bb
LABEL DELIMITER: i RESPONSE MODE: cc
START CHAR: j HOST PROTOCOL: dd
END MESSAGE: k DEVICE ADDRESS: ee
TRANSMISSION CHECK: l
HEADER MESSAGE: m
NO-READ MESSAGE: n
CODE 39 CHECK CHAR: o SEND: p ---PACKAGE DETECT INPUT---
I 2-OF-5 CHECK CHAR: q SEND: r FILTER: ff
CODABAR CHECK CHAR:
s
SEND: t SENSE: gg
Commands: ESC Change: SPACE Cursor Control: ARROWS
Figure 4.1
Setup Screen #1
Setup Screen #1
