Page 53

Chapter 4
Configuring Your Decoder

4–26

Reference

Letter

Description

Field

Type

Options (Select Field

Only)

Valid Entries (Edit Field

Only)

Match table entry.

Edit

N/A

Any ASCII character string
up to 32 characters
maximum. The ?
character will result in a
match with any ASCII
character.

①

Conditions for Output.

Select

None,
Match Entry In Table,
Match–Complete,
Read (Package),
No–Read (Package),
Read and No–Match,
No–Read or
No–Match,
Auto Load
Auto Load (INPUT)

②③

N/A

Duration of output pulse (milliseconds).

Edit

N/A

Numeric value from 10
through 9999. 0 indicates
no pulse.

Output Condition.

N/A

Outputs are enabled or
disabled by responding to
the prompt prior to
entering the configuration
screens, refer to page 4–8.

①

You can enter non-printable control characters in this field, refer to the table on Page 4-12.

②

Auto Load and Auto Load (INPUT) will not turn an output on or off. The decoder will change an auto load field to Match Entry in table after the

auto load.

③

Auto Load (INPUT) only applies to the #8 module position.

Bar Code Types

CODE 39 ENABLE (a) - Selecting YES will enable the decoder to decode
Code 39 bar code labels. Code 39 bar code labels will not be decoded if NO
is selected.

INTERLEAVED 2-OF-5 ENABLE (b) - Selecting YES will enable the
decoder to decode Interleaved 2-of-5 bar code labels. Interleaved 2-of-5 bar
code labels will not be decoded if NO is selected.

Note: Case Code labels are read as two separate Interleaved 2-of-5 labels; ie.
2 fields per scan.

CODE 128 ENABLE (c) - Selecting YES will enable the decoder to decode
Code 128 bar code labels. Code 128 bar code labels will not be decoded if
NO is selected.

Setup Screen #2 Fields
