Chapter 4
Configuring Your Decoder
4–15
Reference
Letter
Description
Field
Type
Options (Select Field
Only)
Valid Entries (Edit Field
Only)
a
Send bar code field data to host.
Select
Yes or No
N/A
b
Send package count to host.
Select
Yes or No
N/A
c
Send bar code type indicator to host.
Select
Yes or No
N/A
d
Send source identification string to host.
Select
Yes or No
N/A
e
Send header message to host.
Select
Yes or No
N/A
f
Send no–read message to host, if
no–read.
Select
Yes or No
N/A
g
Expand UPC–E bar codes.
Select
Yes or No
N/A
h
Source identification message.
Edit
N/A
Up to four ASCII
characters.
①
i
Label delimiter character.
Edit
N/A
Numeric ASCII code ( 0 to
255) 255 = None. Refer
to Appendix C.
j
Start character.
Edit
N/A
Numeric ASCII code ( 0 to
255) 255 = None. Refer
to Appendix C.
k
End of message.
Select
None, CRLF, CR, LF,
ETX
N/A
l
Transmission check method.
Select
None, LRC,
Checksum–LSB,
Checksum–MSB
N/A
m
Header message.
Edit
N/A
Up to 32 ASCII
characters.
①
n
No–read message.
Edit
N/A
Up to 32 ASCII
characters.
①
o
Employ check character for Code 39.
Select
Yes or No
N/A
p
Send Code 39 check character.
Select
Yes or No
N/A
q
Employ check character for Interleaved
2–of–5.
Select
Yes or No
N/A
r
Send Interleaved 2–of–5 check
character.
Select
Yes or No
N/A
s
Employ check character for Codabar.
Select
Yes or No
N/A
t
Send Codabar check character.
Select
Yes or No
N/A
①
You can enter non-printable characters in these fields, refer to the table on page 4-12.
