Chapter 10
Specifications
10–2
Pulse Durations: Programmable from 10 to 9999 milliseconds
(0 disables output) Accuracy
±
5
milliseconds.
Conditions for Output: Read (Package), No-Read (Package),
Match-Complete, Match Entry, Read and
No-Match, No-Read or No-Match.
Electrical Characteristics See following tables.
Output Modules
Catalog No. 1781-0B5S 1781-0A5S 1781-0M5S
Nominal Line Voltage -- 120 VAC 240 VAC
Maximum Line Voltage 60 VDC 140 VAC 280 VAC
Minimum Line Voltage 3.0 VDC 12 VAC 24 VAC
Maximum Peak Off State Voltage 60 VDC 400 V Peak 600 V Peak
Maximum Off-State Leakage 1.0 mA 2.5 mA RMS 4.0 mA RMS
Static off-state dv/dt -- 200 V/ usec 200 V/ usec
Maximum On-State Current 0.5 A DC 0.5 A RMS 0.5 A RMS
Minimum On-State Current 10 mA DC 50 mA RMS 50 mA RMS
Maximum 1 Cycle Surge -- 4.0 A Peak 4.0 A Peak
Maximum 1 Second Surge 1.5 A DC -- --
Peak On-State Voltage 1.5 V DC 1.6 V Peak 1.6 V Peak
Input Modules
Catalog No. 1781-IB5S 1781-IA5S 1781-IM5S
Maximum Input Voltage 32 VDC 140V RMS/AC 280 V RMS/AC
Minimum Input Voltage 3.3 VDC 90V RMS/AC 180 V RMS/AC
Input Resistance 1k ohm - -
Maximum Input Current 32mA DC @
32 VDC
10mA RMS
@ 140
VRMS
8mA RMS
@ 280
VRMS
Drop Out Current 1.0 mA DC 2.5 mA RMS 1.5 mA RMS
Allowable Off State Input Current 1.0 mA DC 3.0 mA RMS 2.0 mA RMS
Allowable Off State Input Voltage 2.0 VDC 50 VRMS/AC 120 VRMS/AC
