Chapter 2
Description of Hardware
2–9
The following table lists the accessories that you may require for use with the
decoder.
Catalog Number Item Description
2755-L7 ①
Industrial Medium Speed Bar Code
Scanner
Raster and side scanning devices that operate at 350 scans per
second. Raster scanners scan both vertical and horizontal directions
simultaneously. Some of these scan heads have a maximum read
distance of 50” (1.27 meters) depending upon symbol size and
quality. Scanners can read Case Code symbols (symbols directly
printed on kraft paper/cardboard boxes).
2755-L9 ① Industrial High Speed Bar Code Scanner
Raster and side scanning devices that operate at 800 scans per
second. Raster scanners scan both vertical and horizontal directions
simultaneously. Some of these scan heads have a maximum read
distance of 30”
(76 cm) depending upon symbol size and quality.
2755-L4F ①
-L4R ①
Enhanced Medium Speed Scanner
Front or side scanners that operate at 200 scans per second. Some
of these scan heads have a maximum read distance of 50” (1.27
meter) depending upon symbol size and quality. Scanners can read
Case Code symbols (symbols directly printed on kraft
paper/cardboard boxes).
2755-L5R ① Enhanced Medium Speed Raster Scanner
Raster scanners that operate at 200 scans per second. This scan
head has a maximum read distance of 45” (1.14 meters) depending
upon symbol size and quality. Scan head scans both vertical and
horizontal directions simultaneously. Scanner can read Case Code
symbols (symbols directly printed on kraft paper/cardboard boxes).
1781-OB5S DC Output Module 3 to 60 VDC output at 0.5 amperes.
1781-OA5S AC Output Module 12 to 140 VAC output at 0.5 amperes.
1781-OM5S AC Output Module 24 to 280 VAC output at 0.5 amperes.
1781-IB5S DC Input Module 3.3 to 32 VDC
1781-IA5S AC Input Module 90 to 140 VRMS/VDC
1781-IM5S AC Input Module 180 to 280 VRMS/VDC
2760-A485 RS-485 Connector Use these connectors to create cables for an RS-485 network.
2755-CL10 10-ft (3.05 meters) Scan Head Cable Use to connect decoder to Catalog No. 2755-L7 or -L9 scan head. ①
2755-CL25 25-ft (7.62 meters) Scan Head Cable Use to connect decoder to Catalog No. 2755-L7 or -L9 scan head. ①
2755-CK10 10-ft (3.05 meters) Scan Head Cable Use to connect decoder to Catalog No. 2755-L4 or -L5 scan head. ①
2755-CK25 25-ft (7.62 meters) Scan Head Cable Use to connect decoder to Catalog No. 2755-L4 or -L5 scan head. ①
W77104-899-01
Replacement Fuse- Power Output
Modules
Plug-in type fuses provide overload protection for the decoder.
Purchased
Locally
Replacement Fuse- Line Input Power 250V ( 1 amp, slow blow), 5 x 20 mm or 3AG
Package
Detector
Assembly
2755-NP3
2755-NP5
2755-NP1
2755-NP4 Optional, for 2755-L7, -L9 Scan Heads
Optional, for 2755-L7, -L9 Scan Heads
Optional, for 2755-L4, -L5 Scan Heads
Optional, for 2755-L4, -L5 Scan Heads
User Created Host Port Communications Cable For connecting host device to the decoder, refer to Chapter 6.
User Created Auxiliary Port Communications Cable
For connecting programming terminal to the decoder. Refer to
Appendix A.
W77121-801-01
W77121-801-02
Power Cords -
120 VAC
220 VAC- Unterminated one end
Replacement power cord.
User must provide suitable connector.
①
We have not provided the complete catalog number since these heads are available in a variety of configurations.
Accessories
