A–B
10 Chapter
10–1
Specifications
Electrical
Input Line Voltage: 85-264 VAC, 47-63 Hz
Power: 50 VA maximum with scan head attached.
Mechanical
Enclosure: Steel (NEMA Type 1)
LED Indicators:
•
POWER
•
LASER ON
•
TRIGGER ACTIVE
•
VALID READ
•
CPU ACTIVE
•
COMMUNICATIONS
•
OUTPUTS 1 through 8
Weight: 8.8 lbs (4.0 kg)
Dimensions: 14” x 10.75” x 2.81”
(356 x 273 x 71 mm)
Environment: Ambient temperature range
32
°
to 122
°
F (0
°
to 50
°
C)
Relative Humidity: 5-95%, noncondensing
Communications
Communication Port
•
RS-422, RS-232, RS-485 (LAN)
(Host)
•
Baud Rates: 300, 1200, 2400, 4800,
9600, 19200, 38400
•
Parity: none, odd, even
•
Data Bits: 7 or 8
•
Stop Bits: 1 or 2
•
Flow Control: None, Xon/Xoff, RTS/CTS
Communication Port
•
Data Bits: 8
(Aux)
•
Stop Bit: 1
•
Baud Rate: 9600
•
Parity: None
Output Modules
Number of Outputs: Two modules provided, up to eight outputs
can be installed.
Decoder - Catalog Number
2755-DM9 & 2755-DM9E
