ASCII Control
Character
Enter:
ASCII Control
Character
Enter:
ASCII Control
Character
Enter:
NUL
%
@
VT
%
K
SYN
%
V
SOH
%
A
FF
%
L
ETB
%
W
STX
%
B
CR
%
M
CAN
%
X
ETX
%
C
SO
%
N
EM
%
Y
EOT
%
D
SI
%
O
SUB
%
Z
ENQ
%
E
DLE
%
P
ESC
%
[
ACK
%
F
DC1
%
Q
FS
%
\
BEL
%
G
DC2
%
R
GS
%
]
BS
%
H
DC3
%
S
RS
%
∧
HT
%
I
DC4
%
T
US
%
_
LF
%
J
NAK
%
U
SELECT FIELDS- To change the contents of a select field, press the
[SPACE] key. After pressing the [SPACE] key, he next option is displayed
and the decoder will display the control keys you can use at the bottom of the
screen. All other keys are ignored:
SELECT -- Cancel:ESC Change:SPACE Enter:RETURN
Press the [SPACE] key again until the option you want is displayed. Press
the [RETURN] key to enter the selected option.
When you first enter either setup screen you will observe the following at the
bottom of the display:
Change:SPACE
Cursor Control: ARROWS
Commands : ESC
Notice that the command bar display provides a quick reference to the
commands used to edit the setup screen. If you select the command bar by
pressing the [ESC] key, the following will be displayed:
COMMAND - - Exit: ESC
Select: RETURN
Next Command: SPACE
NEXT PAGE
THIS PAGE
RECALL
SAVE
DEFAULT
After selecting the command bar, you will notice that the first command
option NEXT PAGE is highlighted in reverse video. To display the other
Command Bar
