Setup screen #2 – Rockwell Automation 2755-DM9, -DM9E High Speed Decoder User Manual
Page 51

Chapter 4
Configuring Your Decoder
4–24
Figure 4.2 shows the second setup screen. We have used lowercase letters to
indicate fields of the configuration data. These letters are keyed to the table
on Page 4-25 and 4-26 which lists the options available for each field type.
Following the table is a short description of the effect each option has on the
operation of the decoder.
-- SYMBOLOGY -- -------- LENGTHS -------- -------- SCANNER CONTROL --------
CODE 39: a
i i i i i i i i
LASER-ON MODE:
m
I 2-OF-5: b
j j j j j j j j DECODE TRIGGER:
n
CODE 128: c
k k k k k k k k
CAPTURE COUNT:
o (scans)
CODABAR: d
l l l l l l l l
FIELDS/SCAN:
p
UPC-A: e
FIELDS/PACKAGE:
q
UPC-E: f
NO-READ TIMER:
r (msec)
EAN-8: g
INTER-SCAN TIMER:
s (msec)
EAN-13: h
MATCH COMPLETE:
t
-----------MATCH CODE TABLE------------- ------------- OUTPUTS [ z ]-------------
1) u v w
x
y
2) u v w
x
y
3) u v w
x
y
4) u v w
x
y
5) u v w
x
y
6) u v w
x
y
7) u v w
x
y
8) u v w
x
y
Commands: ESC Change: SPACE Cursor Control: ARROWS
Figure 4.2
Setup Screen #2
Reference
Letter
Description
Field
Type
Options (Select Field
Only)
Valid Entries (Edit Field
Only)
a
Code 39 symbology enable.
Select
Yes or No
N/A
b
Interleaved 2–of–5 symbology enable.
Select
Yes or No
N/A
c
Code 128 symbology enable
Select
Yes or No
N/A
d
Codabar symbology enable.
Select
Yes or No
N/A
e
UPC–A symbology enable.
Select
Yes or No
N/A
f
UPC–E symbology enable.
Select
Yes or No
N/A
g
EAN–8 symbology enable.
Select
Yes or No
N/A
h
EAN–13 symbology enable.
Select
Yes or No
N/A
i
Specified code lengths for Code 39.
Includes check character. Does not
include start and stop characters.
Edit
N/A
Numeric entries from 0
through 64. 0 indicates no
length check.
Setup Screen #2
