4-24 Configuration and Programming
M0 File Words - Sequencer
Mode For more information on M0 files, refer to Appendix B. Refer to
Appendix E for Sequencer Mode operation worksheets.
M0:e.0 Output Source Select
R R R R R R
R
Output Source Select, Word 0
Bit Number (decimal)
Output Source Select
15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
M0:e.0
Setup and Control Word, Word 1
Valid Steps 1–16, Word 2
Initial Outputs and Valid Steps 17–24, Word 3
Step 2 and Step 1 Outputs, Word 4
Step 4 and Step 3 Outputs, Word 5
M0:e.1
M0:e.2
M0:e.3
M0:e.4
M0:e.5
Rate Period, Word 16
Step 1 Preset, Word 17
M0:e.16
M0:e.17
Step 2 Preset, Word 18 M0:e.18
Reset Value / Maximum Count Value, Word 41 M0:e.41
R R R R R R R R
Soft
Output
Patterns
Step 22 and Step 21 Outputs, Word 14
Step 24 and Step 23 Outputs, Word 15
M0:e.14
M0:e.15
Step 23 Preset, Word 39 M0:e.39
Step 24 Preset, Word 40 M0:e.40
Physical
Output
Patterns
R R R R
R = Reserved, must be reset to 0
R
M0 Word 0
Bit Number (decimal) 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
M0:e.0
Output Source Select
Soft Outputs
Output Source Select
Physical Outputs
R R R R R R R R
