Publication 1746-UM006B-EN-P - August 2005
5-4 Start-Up, Operation, and Troubleshooting
The parameter that caused the error is indicated in the Configuration
Error Code field (I:e.4/0-7). The table below lists the configuration
error code and indicates the required action to clear the error.
Application Errors
The module can encounter the following application errors.
Linear Counter Overflow/Underflow
When the maximum count is exceeded, the Over/Underflow bit
(I:e.0/13) is set to 1. Clearing this error requires reconfiguration. The
module controlled outputs are reset to 0 while this error is present.
Outputs controlled by the user program are not affected.
Rate Counter Overflow
When the Rate Counter exceeds 32,767, the Rate Counter Overflow bit
(I:e.0/4) is set to 1. The module will continue to run the rate
measurement and will clear this error if the input frequency drops
enough to avoid the counter overflow.
This error can also be cleared by the user program reducing the Rate
Period parameter. If operating in the Rate Mode, the module
controlled outputs are reset to 0 while this error is present. Outputs
controlled from the user program are not affected.
Configuration
Error Code Reason Critical
Error Action
Hex Binary
01 0000 0001 not defined -
reconfigure
(1)
(1) The Function Control bit must be reset to 0, the parameter must be changed, and the Function Control bit is
then set to 1 .
02 0000 0010 max count = 0 (ring) yes
reconfigure
(1)
03 0000 0011 invalid operating mode yes
reconfigure
(1)
04 0000 0100 invalid input type yes
reconfigure
(1)
05 0000 0101 static parameter changed yes
reconfigure
(1)
06 0000 0110 ranges active = 0 no change parameter
07 0000 0111 rate period = 0 no change parameter
08 0000 1000 linear counter reset value out of range no change parameter
09 0000 1001 sequencer preset > max. count no change parameter
