6-32 Application Examples

Step Preset Values (decimal) (page 4-34)

Reset Value/Maximum Count Value (page 4-35)

Shown below is the Sequencer Mode Configuration Worksheet for the
Input Data File. A blank worksheet is supplied in Appendix E.

M0:e.17

M0:e.18

M0:e.19

M0:e.20

M0:e.21

M0:e.22

M0:e.23

M0:e.24

M0:e.25

M0:e.26

M0:e.27

M0:e.28

Step 1 Preset

Step 2 Preset

Step 3 Preset

Step 4 Preset

Step 5 Preset

Step 6 Preset

Step 7 Preset

Step 8 Preset

Step 9 Preset

Step 10 Preset

Step 11 Preset

Step 12 Preset

M0:e.29

M0:e.30

M0:e.31

M0:e.32

M0:e.33

M0:e.34

M0:e.35

M0:e.36

M0:e.37

M0:e.38

M0:e.39

Step 13 Preset

Step 14 Preset

Step 15 Preset

Step 16 Preset

Step 17 Preset

Step 18 Preset

Step 19 Preset

Step 20 Preset

Step 21 Preset

Step 22 Preset

Step 23 Preset

M0:e.40

Step 24 Preset

ATTENTION

The module will fault on power-up if you do not
enter a value.

IMPORTANT

The data contained in the Input Data File varies,
depending on the step number. The following cross
section of time was taken 700 counts after the Step 2
Preset was reached.

M0:e.41

Reset Value/Maximum Count Value

Ring counter – Maximum Count Value range is 1 to 32767 (rollover at +32767)
Linear counter – Reset Value range is –32767 to +32767.
