Publication 1746-UM006B-EN-P - August 2005

Sequencer Mode Configuration Worksheets E-3

Step Outputs (page 4-33)

Rate Period (decimal) (page 4-33)

Step Preset Values (decimal) (page 4-34)

M0:e.4

M0:e.5

M0:e.6

M0:e.7

M0:e.8

M0:e.9

M0:e.10

M0:e.11

M0:e.12

M0:e.13

M0:e.14

M0:e.15

Bit Number (decimal)

15

14

13

12

11

10

9

8

7

6

5

4

3

2

1

0

Output Number

7

6

5

4

3

2

1

0

7

6

5

4

3

2

1

0

Step 1 Outputs

Step 3 Outputs

Step 5 Outputs

Step 7 Outputs

Step 9 Outputs

Step 11 Outputs

Step 13 Outputs

Step 15 Outputs

Step 17 Outputs

Step 19 Outputs

Step 21 Outputs

Step 23 Outputs

Step 2 Outputs

Step 4 Outputs

Step 6 Outputs

Step 8 Outputs

Step 10 Outputs

Step 12 Outputs

Step 14 Outputs

Step 16 Outputs

Step 18 Outputs

Step 20 Outputs

Step 22 Outputs

Step 24 Outputs

ATTENTION

The module will fault on power-up if you do not
enter a value.

M0:e.16

Rate Period

1 to 255 = 10 ms to 2.55 seconds

M0:e.17

M0:e.18

M0:e.19

M0:e.20

M0:e.21

M0:e.22

M0:e.23

M0:e.24

M0:e.25

M0:e.26

M0:e.27

M0:e.28

Step 1 Preset

Step 2 Preset

Step 3 Preset

Step 4 Preset

Step 5 Preset

Step 6 Preset

Step 7 Preset

Step 8 Preset

Step 9 Preset

Step 10 Preset

Step 11 Preset

Step 12 Preset

M0:e.29

M0:e.30

M0:e.31

M0:e.32

M0:e.33

M0:e.34

M0:e.35

M0:e.36

M0:e.37

M0:e.38

M0:e.39

Step 13 Preset

Step 14 Preset

Step 15 Preset

Step 16 Preset

Step 17 Preset

Step 18 Preset

Step 19 Preset

Step 20 Preset

Step 21 Preset

Step 22 Preset

Step 23 Preset

M0:e.40

Step 24 Preset
