Publication 1746-UM006B-EN-P - August 2005
A-2 Specifications
Limit Switch Input
Outputs (Open Collector,
Sinking)
Timing Information
Description
Specification
5V dc 12V dc 24V dc
On-State Voltage 3.8 to 5.4V dc 9.4 to 16.5V dc 16.5 to 30V dc
Off-State Voltage 0 to 1.2V dc 0 to 2.4V dc 0 to 3.9V dc
Input Current
minimum
nominal
maximum
4.6 mA
6.8 mA
9.2 mA
Max. Off-State
Leakage Current 1 mA (all ranges)
Isolation (from
backplane) 1500 volts
Description
Specification
4.5 to 10V dc
(Switch 2 on) 10 to 30V dc
(Switch 2 off)
Max. On-State Output
Current 16 mA at 4.5V dc
40 mA at 10V dc 40 mA at 10V dc
125 mA at 30V dc
Max. On-State Voltage Drop 0.4V dc 1.0V dc
Max. Off-State Leakage
Current 100 µA
Isolation (from backplane) 1500 volts
Operation Description Timing
(2)
Throughput The delay time between the module receiving a pulse and the
updating of its physical outputs. Sequencer: 1.8 ms
Range: 3.9 ms
Rate: 70.0 ms +
Rate Period
Minimum wait time between
range boundaries Minimum amount of time (between range or step boundaries)
required to ensure a range or sequencer step is not missed. Sequencer: 2.5 ms
Range: 3.0 ms
Rate: 70.0 ms +
Rate Period
Input file update time The time required for the module to make a change of input status
(I:e.0 to I:e.7) available to the user program. Sequencer: 45 ms
Range: 60 ms
Rate: 35 ms
Physical output response time
(under SLC control) The time required for the module's Direct Outputs Field to respond
to control commands from the user program. Sequencer: 45 ms
Range: 60 ms
Rate: 35 ms
Z input reset response time.
Reset to zero (0) The time required for the module to respond to an external Z input
event and reset the pulse counter to 0.
4.0 µs
(3)
