Configuring the Module 3-3
The 1769-SM2 module has two methods of configuration, which are
determined by the Configuration Mode Switch (SW1 in
Figure 2.1 ):
•
Controller mode—The 1769-SM2 uses the configuration data
downloaded from the controller on power-up and when the controller
is placed in run mode. The data is configured using RSLogix 500,
RSLogix 5000 or RSNetWorx for DeviceNet.
•
Parameter mode—The 1769-SM2 uses its internal parameter settings
to configure the module. The data is configured using an optional,
external PowerFlex 4-Class HIM, DriveExplorer, or DriveExecutive.
Only one method can be selected, and it is used for all three channels.
When the Configuration Mode Switch (SW1 in Figure 2.1 ) is in the
default CONT (Controller) position, the 1769-SM2 uses the configuration
data downloaded from the controller on power-up and when the controller
is placed in run mode. Depending on the controller, configuration data is
allocated and entered using RSLogix500 or RSLogix 5000.
Configuration Data
The 1769-SM2 module contains a set of 42 words of configuration data
that is used to configure the module's behavior (
Table 3.C ). A software
tool, such as RSLogix 500, RSLogix 5000 or RSNetWorx for DeviceNet
is used to read/write the configuration data.
Configuration Methods
Controller Mode
Table 3.C 1769-SM2 Module Configuration Data
Parameter Name CH1 CH2 CH3
Idle Action Word 0 Word 14 Word 28
Flt Cfg Logic Word 1 Word 15 Word 29
Flt Cfg Ref Word 2 Word 16 Word 30
DSI I/O Cfg Word 3 Word 17 Word 31
Drive 0 Addr Word 4 Word 18 Word 32
Drive 1 Addr Word 5 Word 19 Word 33
Drive 2 Addr Word 6 Word 20 Word 34
Drive 3 Addr Word 7 Word 21 Word 35
Drive 4 Addr Word 8 Word 22 Word 36
RTU Baud Rate Word 9 Word 23 Word 37
RTU Format Word 10 Word 24 Word 38
RTU Rx Delay Word 11 Word 25 Word 39
RTU Tx Delay Word 12 Word 26 Word 40
RTU Msg Timeout Word 13 Word 27 Word 41
