Index-3

H

HIM (Human Interface Module)

accessing parameters with, 3-13
definition, G-3

hold last

configuring the module for, 3-15
definition, G-3

I

I/O

configuring the module for, 3-14
definition, G-3
image examples, 3-2, 4-2
image table, 3-1, 4-1
module control word, 4-2
module status word, 4-3
understanding the I/O image, 4-1
using Reference/Feedback, 4-4

Identity object, C-3

idle action

configuring the module for, 3-15
definition, G-3

Idle Action 1 parameter, B-2

Idle Action 2 parameter, B-4

Idle Action 3 parameter, B-6

installation

applying power to module, 2-14
connecting drives to module, 2-10
preparing for, 2-1
removing power from module, 2-2

L

LEDs, see status indicators

Logic Command/Status word

bit definitions, D-1, D-2
definition, G-3

M

manual

conventions, P-3
related documentation, P-1
web site, P-1

messaging, see Explicit Messaging

MicroLogix 1500 example ladder

program

Multi-Drive mode

1769-SM2 settings, 6-10
20-COMM-H settings, 6-10
CH3 Modbus RTU Master

subroutine example, 6-18 to
6-22

main routine/subroutines, 6-12

to 6-15

PowerFlex 40 settings, 6-9
PowerFlex 70 setting, 6-9
program data tables, 6-16
system arrangement, 6-9

Single mode

1769-SM2 settings, 6-2
main routine/subroutines, 6-4

to 6-6

PowerFlex 40 settings, 6-2
program data table, 6-7
system arrangement, 6-2
