Appendix
C
CIP/DSI Objects
Appendix C presents information about the CIP and DSI objects that can
be accessed using Explicit Messages.
For information on formatting Explicit Messages and example ladder
logic programs, refer to the corresponding chapter:
•
Chapter 5 , Understanding Explicit Messaging
•
Chapter 6 , MicroLogix 1500 Example Ladder Programs
•
Chapter 7 , CompactLogix Example Ladder Programs
•
Chapter 8 , ControlLogix w/1769-ADN DeviceNet Example Ladder
Program
Object Class Code Page
Hex. Dec.
CIP Identity Object 0x01 1 C-3
CIP Parameter Object 0x0F 15 C-4
DSI Device Object 0x92 146 C-7
DSI Parameter Object 0x93 147 C-10
DSI Fault Object 0x97 151 C-14
DSI Diagnostic Object 0x99 153 C-16
TIP: Refer to the CIP Common specification for more information
about CIP objects. Information about the CIP Common specification is
available on the ODVA web site (
http://www.odva.org ).
