7-20

CompactLogix Example Ladder Programs

A “17486” equates to Parameter 78 (17486 - 17408 = 78), since 17408 is
Instance 0 in the drive (17409 is Parameter 1). For additional information
about the message setup, refer to

page 5-3

.

Write Message (Rung 17)

A “17486” equates to Parameter 78 (17486 - 17408 = 78), since 17408 is
Instance 0 in the drive (17409 is Parameter 1). For additional information
about the message setup, refer to

page 5-3

.
