Module Parameters
B-3
08
[DSI I/O Act 1]
Displays the CH1 drives that are active in
Multi-Drive mode.
Default:
xxx0 0000
Bit Values:
0 = Drive Active
1 = Drive Inactive
Type:
Read Only
09
10
11
12
13
[Drv 0 Addr 1]
[Drv 1 Addr 1]
[Drv 2 Addr 1]
[Drv 3 Addr 1]
[Drv 4 Addr 1]
Sets the corresponding node addresses of the
daisy-chained CH1 drives when the module is in
Multi-Drive mode.
Important: The setting for each of these
parameters must match the drive Parameter 104 -
[Comm Node Addr] value for each respective
drive. Each drive node address must be unique
(no duplicate node addresses).
Default:
100
Default:
100
Default:
100
Default:
100
Default:
100
Minimum:
0
Maximum:
247
Type:
Read/Write
Reset Required:
Yes
14
[RTU Baud Rate 1]
Sets the baud rate used by the CH1 drives when
the module is in Multi-Drive mode and Parameter
07 - [DSI I/O Cfg 1] is set to “5” (RTU Master).
Default:
0 = 38.4K bps
Values:
0 = 38.4K bps
1 = 19200 bps
2 = 9600 bps
3 = 4800 bps
4 = 2400 bps
5 = 1200 bps
6 = 600 bps
7 = 300 bps
Type:
Read/Write
Reset Required:
Yes
15
[RTU Format 1]
Selects the RTU format used by the CH1 drives
when the module is in Multi-Drive mode and
Parameter 07 - [DSI I/O Cfg 1] is set to “5” (RTU
Master). The RTU format consists of three
components: data bits (8 data bits only), parity
(None, Even or Odd), and stop bits (1 or 2).
Default:
0 = 8-N-1
Value:
0 = 8-N-1
1 = 8-E-1
2 = 8-O-1
3 = 8-N-2
4 = 8-E-2
5 = 8-O-2
Type:
Read/Write
Reset Required:
Yes
16
[RTU Rx Delay 1]
Sets the CH1 inter-character delay used to detect
the end of a receive packet when the module is in
Multi-Drive mode and Parameter 07 - [DSI I/O
Cfg 1] is set to “5” (RTU Master). If this value is
set to 0 (zero), the ModBus default delay of 1.5
character times is used.
Default:
0 milliseconds
Minimum:
0 milliseconds
Maximum:
500 milliseconds
Type:
Read/Write
Reset Required:
Yes
Parameter
No. Name and Description
Details
Bit
Definition
Not Us
ed
Not Us
ed
Not Us
ed
Dr
iv
e 4
Dr
iv
e 3
Dr
iv
e 2
Dr
iv
e 1
Dr
iv
e 0
Default
x
x
x
0
0
0
0
1
Bit
7
6
5
4
3
2
1
0
