Troubleshooting

9-7

7-9

Reserved

DSI Events

10

Slave Detected The module detected that the slave has been connected.

11

Slave Removed The module detected that the slave has been disconnected.

12

Slave Logon

The module has established communications with the slave.

13

Slave Timeout

The module has lost communications with the slave.

14

Slave Brand Flt The slave brand is different than the module.

15

Host 0 Logon

The module has established communications with host 0.

16

Host 1 Logon

The module has established communications with host 1.

17

Host 2 Logon

The module has established communications with host 2.

18

Host 3 Logon

The module has established communications with host 3.

19

Host 4 Logon

The module has established communications with host 4.

20

Host 0 Timeout The module has lost communications with host 0.

21

Host 1 Timeout The module has lost communications with host 1.

22

Host 2 Timeout The module has lost communications with host 2.

23

Host 3 Timeout The module has lost communications with host 3.

24

Host 4 Timeout The module has lost communications with host 4.

25

Host 0 Brand Flt The host 0 brand is different than the module.

26

Host 1 Brand Flt The host 1 brand is different than the module.

27

Host 2 Brand Flt The host 2 brand is different than the module.

28

Host 3 Brand Flt The host 3 brand is different than the module.

29

Host 4 Brand Flt The host 4 brand is different than the module.

Network Events

40

Net Link Up

The network link is established.

41

Net Link Down

The network link is lost.

42

Dup Net Addr

The module has detected that another device is using its
network address. In this case, the module will not participate in
any network activity.

43

Net Open

An I/O connection from the network to the module was opened.

44

Net Close

An I/O connection from the network to the module was closed.

45

Net Timeout

An I/O connection from the network to the module has timed
out.

46

Net Comm Flt

The module has performed the “Comm Flt” action specified by
the user.

47

Net Idle Flt

The module has performed the “Idle Flt” action specified by the
user.

48

PCCC IO Open The module has begun receiving PCCC Control messages (the

PCCC Control Timeout was previously set to a non-zero value).

49

PCCC IO Close The device sending PCCC Control messages to the module

has set the PCCC Control Timeout to a value of zero.

50

PCCC IO Time
Flt

The module has not received a PCCC Control message for
longer than the PCCC Control Timeout.

51

Net Sent Reset The module received a reset from the network.

Table 9.C Module Events (Continued)

Code Event Description
