Publication 1762-UM001G-EN-P - March 2011
A-2 Specifications
Shock Operating: 30G; 3 pulses each direction, each axis
Relay Operation: 7G
Non-Operating: 50G panel mounted (40G DIN Rail mounted); 3 pulses each direction, each axis
Agency certification
•
UL 508
•
C-UL under CSA C22.2 no. 142
•
Class I, Div. 2, Groups A, B, C, D
(UL 1604, C-UL under CSA C22.2 no. 213)
•
CE/C-Tick compliant for all applicable directives/acts
Electrical/EMC The controller has passed testing at the following levels:
•
EN 61000-4-2: 4 kV contact, 8 kV air, 4 kV indirect
•
EN 61000-4-3: 10V/m, 80 to 1000 MHz, 80% amplitude modulation, +900 MHz keyed carrier
•
EN 61000-4-4: 2 kV, 5 kHz; communications cable: 1 kV, 5 kHz
•
EN 61000-4-5: communications cable 1 kV galvanic gun
I/O: 2 kV CM (common mode), 1 kV DM (differential mode)
AC Power Supply: 4 kV CM (common mode), 2 kV DM (differential mode)
DC Power Supply: 500V CM (common mode), 500V DM (differential mode)
•
EN 61000-4-6: 10V, communications cable 3V
Terminal screw torque 0.791 Nm (7 in-lb) rated
(1) Do not allow the total load power consumed by the 5V dc, 24V dc, and sensor power outputs to exceed 12W.
(2) Do not allow the total load power consumed by the 5V dc, 24V dc, and sensor power outputs to exceed 16W.
See Appendix F for system validation worksheets.
Table A.1 General
Attribute 1762-
L24AWA
L24AWAR L24BWA
L24BWAR L24BXB
L24BXBR L40AWA
L40AWAR L40BWA
L40BWAR L40BXB
L40BXBR
Table A.2 Input Specifications
Attribute 1762-L24AWA
1762-L40AWA
1762-L24AWAR
1762-L40AWAR 1762-L24BWA, -L24BXB, -L40BWA, -L40BXB
1762-L24BWAR, -L24BXBR, -L40BWAR, -L40BXBR
Inputs 0 through 3 Inputs 4 and higher
On-state voltage range 79…132V ac 14…24V dc
(+10% at 55 °C/131 °F)
(+25% at 30 °C/86 °F) 10…24V dc
(+10% at 55 °C/131 °F)
(+25% at 30 °C/86 °F)
Off-state voltage range 0…20V ac 0…5V dc
Operating frequency 47…63 Hz 0 Hz…20 kHz 0 Hz…1 kHz
(scan time dependent)
On-state current:
•
minimum
•
nominal
•
maximum
•
5.0 mA at 79V ac
•
12 mA at 120V ac
•
16.0 mA at 132V ac
•
2.5 mA at 14V dc
•
7.3 mA at 24V dc
•
12.0 mA at 30V dc
•
2.0 mA at 10V dc
•
8.9 mA at 24V dc
•
12.0 mA at 30V dc
