Publication 1762-UM001G-EN-P - March 2011
Specifications A-23
Combination Module DC-Input/Relay Output
Table A.28 DC-Input/Relay-Output Combination Module - 1762-IQ80W6 Input
Specifications
Specification Value
Voltage category
24V dc (Sink/Source)
(1)
(1) Sinking/Sourcing Inputs - Sinking/Sourcing describes the current flow between the I/O module and the field
device. Sourcing I/O circuits supply (source) current to sinking field devices. Sinking I/O circuits are driven by
a current sourcing field device. Field devices connected to the negative side (DC Common) of the field power
supply are sinking field devices. Field devices connected to the positive side (+V) of the field supply are
sourcing field devices.
Operating voltage range 10…30V dc @ 30 °C (86 °F)
10…26.4V dc @ 65 °C (149 °F)
Number of inputs 8
On-state voltage, min. 10V dc
Off-state voltage, max. 5V dc
On-state current, min. 2.0 mA
Off-state current, max. 1.5 mA
Inrush current, max. 250 mA
Nominal impedance 3 k
Ω
Input compatibility IEC Type 1+
Signal delay time, max. On-delay: 8 ms
Off-delay: 8 ms
Table A.29 DC-Input/Relay-Output Combination Module - 1762-IQ80W6 Output
Specifications
Specification Value
Voltage range 5…265V ac
5…125V dc
Commons per module 6
Output type 6-Form A (normally open)
Signal delay time On-delay: 10 mS (max) Off-delay: 10 mS (max)
Off leakage current 0 mA
On-state current, min. 10 mA @ 5V dc
Continuous current per
point See table on page A-24.
Continuous current per
module 8 A
Total controlled load 1440VA/Module max
