Publication 1762-UM001G-EN-P - March 2011
A-12 Specifications
Vendor I.D. code 1
Product type code 7
Product code 119 101 103 100
Table A.14 Output Specifications
Specification 1762-OA8 1762-OB8 1762-OB16 1762-OB32T
Table A.15 Output Specifications
Specification 1762-OV32T 1762-OW8 1762-OW16 1762-OX6I
Shipping weight, approx.
(with carton) 200 g (0.44 lbs.) 228 g (0.50 lbs.) 285 g (0.63 lbs.) 220 g (0.485 lbs)
Voltage category 24V dc sink AC/DC normally open
relay AC/DC normally open
relay AC/DC Type C Relay
Operating voltage range 10.2…26.4V dc 5…265V ac
5…125V dc 5…265V ac
5…125V dc 5…265V ac
5…125V dc
Number of outputs 32 8 16 6
Bus current draw, max. 175 mA at 5V dc
0 mA at 24V dc 80 mA at 5V dc (0.40 W)
90 mA at 24V dc (2.16 W) 140 mA at 5V dc (0.70 W)
180 mA at 24V dc
(4.32 W)
(1)
110 mA at 5V dc (0.55 W)
110 mA at 24V dc
(2.64 W)
Heat dissipation, max. 2.7 W at 26.4V dc 2.9 W
6.1 W (1) 2.8 W
Signal delay, max. –
resistive load On delay: 0.5 ms
Off delay: 4.0 ms On delay: 10 ms
Off delay: 10 ms On delay: 10 ms
Off delay: 10 ms On delay:
10 ms (max)
6 ms (typical)
Off Delay:
20 ms (max)
12 ms (typical)
Off-state leakage, max. 0.1 mA at 26.4V dc 0 mA 0 mA 0 mA
On-state current, min. 1.0 mA 10 mA 10 mA 100 mA
On-state voltage drop,
max. 0.3V dc at 0.5A Not applicable Not applicable Not applicable
Continuous current per
point, max. 0.5A at 60 °C (140 °F) 2.5 A (Also see “Relay Contact Ratings” on page A-6.) 7A (Also see “Relay
Contact Ratings” on
page A-6.)
Continuous current per
common, max. 2.0 A at 60 °C (140 °F) 8 A 8A 7A (Also see “Relay
Contact Ratings” on
page A-6.)
Continuous current per
module, max. 4.0 A at 60 °C (140 °F) 16 A 16A 30A (Also see Module
Load Ratings 1762-OX6I
on page A-14.
Surge current, max. 2.0 A (Repeatability is
once every 2 s at 60 °C
(140 °F) for 10 ms) See “Relay Contact Ratings” on page A-6 See “Relay Contact
Ratings” on page A-6.
Power supply distance
rating 6 (The module may not be more than 6 modules away from the power supply.)
