Publication 1762-UM001G-EN-P - March 2011
Specifications A-11
Bus current draw, max. 115 mA at 5V dc
(0.575 W) 115 mA at 5V dc (0.575
W) 175 mA at 5V dc (0.88 W) 175 mA at 5V dc
0 mA at 24V dc
Heat dissipation, max. 2.9 W 1.61 W 2.9 W at 30 °C (86 °F)
2.1 W at 55 °C (131 °F) 3.4 W at 26.4 dc
Signal delay, max. –
resistive load On delay: 1/2 cycle
Off delay: 1/2 cycle On delay: 0.1 ms
Off delay: 1.0 ms On delay: 0.1 ms
Off delay: 1.0 ms On delay: 0.5 ms
Off delay: 4.0 ms
Off-state leakage, max. 2 mA at 132V,
2.5 mA at 265V 1.0 mA 1.0 mA 0.1 mA at 26.4V dc
On-state current, min. 10 mA 1.0 mA 1.0 mA 1.0 mA
On-state voltage drop,
max. 1.5V at 0.5 A 1.0V dc 1.0V dc 0.3V dc at 0.5 A
Continuous current per
point, max. 0.25 A at 55 °C (131 °F)
0.5 A at 30 °C (86 °F) 0.5 A at 55 °C (131 °F)
1.0 A at 30°C (86 °F) 0.5 A at 55°C (131 °F)
1.0 A at 30°C (86 °F) 0.5 A at 60 °C (140 °F)
Continuous current per
common, max. 1.0 A at 55 °C (131 °F)
2.0 A at 30 °C (86 °F) 4.0A at 55°C (131 °F)
8.0A at 30°C (86°F) 4.0 A at 55°C (131 °F)
8.0 A at 30°C (86 °F) 2.0 A at 60 °C (140 °F)
Continuous current per
module, max. 2.0 A at 55°C (131°F)
4.0 A at 30°C (86°F) 4.0 A at 55°C;
8.0 A at 30°C 4.0 A at 55°C (131 °F)
8.0 A at 30°C (86 °F) 4.0 A at 60 °C (140 °F)
Surge current, max. 5.0 A (Repeatability is
once every 2 seconds for
a duration of 25 ms.) 2.0A (Repeatability is
once every 2 seconds at
55 °C (131 °F), once every
second at 30 °C (86 °F)
for a duration of 10 ms.) 2.0A (Repeatability is
once every 2 seconds at
55 °C (131 °F), once every
second at 30 °C (86 °F)
for a duration of 10 ms.) 2.0 A (Repeatability is
once every 2 s at 60 °C
(140 °F) for 10 ms.)
Power supply distance
rating 6 (The module may not be more than 6 modules away from the power supply.)
Isolated groups Group 1:
Outputs 0 to 3
Group 2:
Outputs 4 to 7 Group 1:
Outputs 0 to 7 Group 1:
Outputs 0 to 15 Group 1: Outputs 0…15
Group 2: Outputs 16…31
(internally connected to
common)
Output group to
backplane isolation Verified by one of the
following dielectric tests:
1836V ac for 1 s or 2596V
dc for 1 s.
265V ac working voltage
(IEC Class 2 reinforced
insulation)
Verified by one of the following dielectric tests:
1200V ac for 1 s or 1697V dc for 1 s.
75V dc working voltage (IEC Class 2 reinforced
insulation)
Verified by one of the
following dielectric tests:
1200V ac for 2 s or 1697V
dc for 2 s.
75V dc working voltage
(IEC Class 2 reinforced
insulation)
Output group to output
group isolation Verified by one of the
following dielectric tests:
1836V ac for 1 s or 2596V
dc for 1 s.
265V ac working voltage
(IEC Class 2 reinforced
insulation)
Not applicable Verified by one of the
following dielectric tests:
1200V ac for 2 s or 1697V
dc for 2 s.
75V dc working voltage
(IEC Class 2 reinforced
insulation)
Table A.14 Output Specifications
Specification 1762-OA8 1762-OB8 1762-OB16 1762-OB32T
