Appendix
A
Specifications
The 1762 specifications include:
• Controller Specifications
• Expansion I/O Specifications
Controller Specifications
Table A.1 General
Attribute 1762-
L24AWA
L24AWAR L24BWA
L24BWAR L24BXB
L24BXBR L40AWA
L40AWAR L40BWA
L40BWAR L40BXB
L40BXBR
Dimensions Height: 90 mm, 104 mm (with DIN latch open)
Width: 110 mm
Depth: 87 mm Height: 90 mm, 104 mm (with DIN latch open)
Width: 160 mm
Depth: 87 mm
Shipping weight 0.9 kg (2.0 lbs) 1.1 kg (2.4 lbs)
Number of I/O 14 inputs and 10 outputs 24 inputs, 16 outputs
Power supply voltage 100 … 240V ac
(-15%, +10%)
at 47…63 Hz 24V dc
(-15%, +10%)
Class 2
SELV 100 … 240V ac
(-15%, +10%)
at 47…63 Hz 24V dc
(-15%, +10%)
Class 2
SELV
Heat dissipation 15.2 W 15.7 W 17.0 W 21.0 W 22.0 W 27.9 W
Power supply inrush
current 120V ac: 25A for 8 ms
240V ac: 40A for 4 ms 24V dc:
15A for 20 ms 120V ac: 25A for 8 ms
240V ac: 40A for 4 ms 24V dc:
15A for 30 ms
Power supply usage 68VA 70VA 27 W 80VA 82VA 40 W
Power
supply
output 5V dc 400 mA
400 mA
(1) 400 mA 600 mA
600 mA
(2) 600 mA
24V dc 350 mA 350 mA (1) 350 mA 500 mA 500 mA (2) 500 mA
Sensor power output none 250 mA at 24V dc
AC Ripple < 500 mV
peak-to-peak
400 µF max.
(1)
none none 400 mA at 24V dc
AC Ripple < 500 mV
peak-to-peak
400 µF max.
(2)
none
Input circuit type 120V ac 24V dc
sink/source 24V dc
sink/source 120V ac 24V dc
sink/source 24V dc
sink/source
Output circuit type Relay Relay Relay/FET Relay Relay Relay/FET
Relay life - Electrical
1 x 10
5
operations min. (at 3A, 250VAC/30 VDC) resistive load
Temperature, operating 0…55 °C (32…131 °F) ambient
Temperature, storage -40…+85 °C (-40…185 °F) ambient
Operating humidity 5…95% relative humidity (non-condensing)
Vibration Operating: 10…500 Hz, 5G, 0.030 in. max. peak-to-peak, 2 hours each axis
Relay Operation: 1.5G
