Publication 1762-UM001G-EN-P - March 2011
Specifications A-13
Isolated groups Group 1: Outputs 0…15
Group 2: Outputs 16…31
(internally connected to
common)
Group 1: Outputs 0 to 3
Group 2: Outputs 4 to 7 Group 1: Outputs 0 to 7
Group 2: Outputs 8 to 15 All 6 Outputs Individually
Isolated.
Output group to
backplane isolation Verified by one of the
following dielectric tests:
1200V ac for 2 s or 1697V
dc for 2 s.
75V dc working voltage
(IEC Class 2 reinforced
insulation)
Verified by one of the following dielectric tests: 1836V ac for 1 s or 2596V dc for
1 s.
265V ac working voltage (IEC Class 2 reinforced insulation)
Output group to output
group isolation Verified by one of the
following dielectric tests:
1200V ac for 2 s or 1697V
dc for 2 s.
75V dc working voltage
(IEC Class 2 reinforced
insulation)
Verified by one of the following dielectric tests: 1836V ac for 1 s or 2596V dc for
1 s.
265V ac working voltage (basic insulation)
150V ac working voltage (IEC Class 2 reinforced insulation)
Vendor I.D. code 1
Product type code 7
Product code 102 120 121 124
(1) Only applicable to Series B I/O modules.
Table A.15 Output Specifications
Specification 1762-OV32T 1762-OW8 1762-OW16 1762-OX6I
Table A.16 Relay Contact Ratings (1762-OW8 and 1762-OW16)
Maximum Volts Amperes Amperes
Continuous Volt-Amperes
Make Break Make Break
240V ac 7.5 A 0.75 A
2.5 A
(2)
(2) 1.5 A above 40 °C (104 °F).
1800VA 180VA
120V ac 15 A 1.5 A
2.5 A
(1) 1800VA 180VA
125V dc
0.22 A
(1)
(1) For dc voltage applications, the make/break ampere rating for relay contacts can be determined by dividing 28
VA by the applied dc voltage. For example, 28VA/48V dc = 0.58 A. For dc voltage applications less than 14 V, the
make/break ratings for relay contacts cannot exceed 2 A.
1.0 A
28VA
24V dc
1.2 A
(2) 2.0 A
