Publication 1762-UM001G-EN-P - March 2011
A-24 Specifications
Table A.30 DC-Input/Relay-Output Combination Module - 1762-IQ80W6 Relay
Contact Ratings
Volts
(max.) Continuous
Amps per
Point (Max.)
Amperes
(1)
(1) Surge Suppression - Connecting surge suppressors across your external inductive load will extend the life of
the relay contacts. For additional details, refer to Industrial Automation Wiring and Grounding Guidelines,
publication 1770-4.1.
Voltamperes
Make Break Make Break
240V ac 2.5 A 7.5 A 0.75 A 1800VA 180VA
120V ac 15 A 1.5 A
125V dc 1.0 A
0.22 A
(2)
(2) For dc voltage applications, the make/break ampere rating for relay contacts can be determined by dividing
28VA by the applied dc voltage. For example, 28VA/48V dc = 0.58 A. For dc voltage applications less than 14 V,
the make/break rating for relay contacts cannot exceed 2 A.
28VA
(2)
24V dc 2.0 A 1.2 A
28VA
(2)
Table A.31 DC-Input/Relay-Output Combination Module - 1762-IQ80W6 General
Specifications
Specification Value
Dimensions 90 mm (height) x 87 mm (depth) x 40.4 mm (width)
height including mounting tabs is 110 mm
3.54 in. (height) x 3.43 in. (depth) x 1.59 in. (width)
height including mounting tabs is 4.33 in.
Shipping weight, approx.
(with carton) 280 g (0.62 lbs.)
Bus current draw, max. 110 mA @ 5V dc
80 mA @ 24V dc
Heat dissipation 5.0 W @ 30V dc
4.4 W @ 26.4V dc
(The Watts per point, plus the minimum W, with all points
energized.)
Power supply distance
rating 6
Isolated group Group 1 (input 0…3)
Group 2 (input 4…7)
Group 3 (output 0…5)
Vibration Operating: 10 to 500 Hz, 5G, 0.030 in. max. peak-to-peak,
2 hours per axis.
Relay Operation: 1.5 G
Shock Operating: 30G panel mounted, 3 pulses per axis
Relay Operation: 7G
Non-Operating: 50G panel mounted, 3 pulses per axis
(40G DIN Rail mounted)
