Publication 1762-UM001G-EN-P - March 2011
Specifications A-9
EFT/B immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-4: 2 kV, 5 kHz on signal ports
For all other modules
IEC1000-4-4: 2 kV, 5 kHz
Surge transient immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-5: 2 kV common mode, 1 kV differential mode
For all other modules
IEC1000-4-5: 2 kV common mode, 1 kV differential mode
Conducted RF immunity For 1762-IQ32T, 1762-OB32T, and 1762-OV32T modules
IEC61000-4-6: 10V, 0.15…80 MHz
(2)
For all other modules:
IEC1000-4-6: 10V, 0.15…80 MHz
(2)
(1) For the exact operating temperature range, refer to the Installation Instructions publication for the specific module.
(2) Conducted Immunity frequency range may be 150 kHz to 30 MHz if the Radiated Immunity frequency range is 30…1000 MHz.
Table A.12 General Specifications
Attribute Value
Table A.13 Input Specifications
Attribute Value
1762-IA8 1762-IQ8 1762-IQ16 1762-IQ32T
Shipping weight, approx.
(with carton) 209 g (0.46 lbs.) 200 g (0.44 lbs.) 230 g (0.51 lbs.) 200g (0.44 lbs.)
Voltage category 100/120V ac
24V dc (sink/source)
(1) 24V dc
(sink/source)footnote>(1) 24V dc
(sink/source)
(1)
Operating voltage range 79…132V ac at
47…63 Hz 10…30V dc at 30 °C
(86 °F)
10…26.4V dc at 55 °C
(131 °F) 10…30V dc
10…26.4V dc )
(3)(2)
10…30V dc (24 points) at
30 °C (86 °F)
10…26.4V dc
(23 points)at 60 °C
(140 °F)
Number of inputs 8 8 16 32
Bus current draw, max. 50 mA at 5V dc (0.25 W) 50 mA at 5V dc (0.25 W) 70 mA at 5V dc
(0.35 W)
(3)
170 mA at 5V dc
0 mA at 24V dc
Heat dissipation, max. 2.0 W 3.7 W 4.3 W at 26.4V
5.4 W at 30V
(3)
5.4 W at 26.4V dc
6.8 W at 30V dc
Signal delay, max. On delay: 20.0 ms
Off delay: 20.0 ms On delay: 8.0 ms
Off delay: 8.0 ms On delay: 8.0 ms
Off delay: 8.0 ms On delay: 8.0 ms
Off delay: 8.0 ms
Off-state voltage, max. 20V ac 5V dc 5V dc 5V dc
Off-state current, max. 2.5 mA 1.5 mA 1.5 mA 1.0 mA
On-state voltage, min. 79V ac (min.)
132V ac (max.) 10V dc 10V dc 10V dc
