F-10 System Loading and Heat Dissipation
Calculating Heat
Dissipation Use the following table when you need to determine the heat dissipation of
your system for installation in an enclosure. For System Loading, take the value
from the appropriate system loading worksheets on pages F-4, F-5, F-8 or F-9:
Table F.17 Heat Dissipation
Catalog Number Heat Dissipation
Equation or Constant Calculation Sub-Total
1762-L24AWA, -L24AWAR 15.2W + (0.4 x System Loading) 15.2W + (0.4 x ______ W) W
1762-L24BWA, -L24BWAR 15.7W + (0.4 x System Loading) 15.7W + (0.4 x ______ W) W
1762-L24BXB, -L24BXBR 17.0W + (0.3 x System Loading) 17.0W + (0.3 x ______ W) W
1762-L40AWA, -L40AWAR 21.0W + (0.4 x System Loading) 21.0W + (0.4 x ______ W) W
1762-L40BWA, -L40BWAR 22.0W + (0.4 x System Loading) 22.0W + (0.4 x ______ W) W
1762-L40BXB, -L40BXBR 27.9W + (0.3 x System Loading) 27.9W + (0.3 x ______ W) W
1762-IA8 2.0W x number of modules 2.0W x _________ W
1762-IF4 2.0W x number of modules 2.0W x _________ W
1762-IF2OF2 2.6W x number of modules 2.6W x _________ W
1762-IQ8 3.7W x number of modules 3.7W x _________ W
1762-IQ16
5.1W
(1)
x number of modules 5.1W
(1)
x _________
W
1762-IQ32T 6.8 W x number of modules (at 30.0V dc)
5.4 W x number of modules (at 26.4V dc) 6.8 W x _________ (at 30.0V dc)
5.4 W x _________ (at 26.4V dc) W
W
1762-IR4 1.5W x number of modules 1.5W x _________ W
1762-IT4 1.5W x number of modules 1.5W x _________ W
1762-OA8 2.9W x number of modules 2.9W x _________ W
1762-OB8 1.6W x number of modules 1.6W x _________ W
1762-OB16 2.9W x number of modules 2.9W x _________ W
1762-OB32T 3.4 W x number of modules 3.4 W x _________ W
1762-OF4 2.8W x number of modules 2.8W x _________ W
1762-OV32T 2.7 W x number of modules 2.7 W x _________ W
1762-OW8 2.9W x number of modules 2.9W x _________ W
1762-OW16
6.1
(1)
W x number of modules 6.1W
(1)
x _________
W
1762-OX6I 2.8W x number of modules 2.8W x _________ W
1762-IQ8OW6 5.0W x number of modules (at 30V dc)
4.4W x number of modules (at 26.4V dc) 5.0W x _________
4.4W x _________ W
W
Add Sub-totals to determine Heat Dissipation W
(1) Only applicable to Series B I/O modules.
