1–9
Installing and Wiring Your ControlNet Adapter Board
Publication 1336 FORCE–5.18 ––March, 1999
4. On some applications, it may be necessary to provide some form
of cable support after removing the strain relief. If your
application involves a long cable droop, or a heavy unsupported
wire bundle, it is recommended you zip tie the fiber optic cable at
a point that will prevent the weight of the cable from being solely
supported by the plug in connectors.
5. If the cable is kinked or nicked during installation, it MUST be
replaced. A kinked or damaged cable greatly reduces signal
strength and could cause the drive to fault.
Cable Type – Recommended cables are shown in the following
table. These cables are available in precut, popular lengths for ease
of use.
Description
200 Micron Cable Assembly 10 meters
200 Micron Cable Assembly 20 meters
200 Micron Cable Assembly 60 meters
200 Micron Cable Assembly 100 meters
200 Micron Cable Assembly 200 meters
200 Micron Cable Assembly 300 meters
Micron Fiber Optic Cable Selection
Catalog Number
1786 – FS10
1786 – FS20
1786 – FS60
1786 – FS100
1786 – FS200
1786 – FS300
IMPORTANT: Only use cables that are approved for ControlNet
Applications. Refer to Bulletin 1786 ControlNet documentation for
details.
Associated Hardware – The 1786-RPA module converts the coax
cable through a CNet coax tap to up to four of the 1786-RPFS
modules. The 1786 RPFS X has two connectors to receive the 200
Micron cable. The Drive ControlNet adapter board also has two
connectors to receive the 200 Micron cable.
Description
ControlNet Modular Repeater Adapter
Short Distance Fiber Module – 300 meters
Module Selection
Catalog Number
1786 – RPA
1786 – RPFS
Note: The 1786-RPA must be powered from a 24 volt power supply
For additional information on repeater modules refer to the following
publications:
1786-2.12 ControlNet Network System Overview
1786-5.12 ControlNet Modular Repeater Short-Distance Fiber
Modular Installation Instructions.
1786–5.13 ControlNet Modular Repeater Adapter Installation
Instructions.
