6–16 Parameters
Publication 1336 FORCE–5.18 ––March, 1999
325 CntlNet Input 3
[CntlNet In 3]
CntlNet In 3 contains the fourth word or data group
from the PLC controller output image table. The
ControlNet scanner transfers the data to the drive
every rack scan. The ControlNet Adapter Board can
use this value directly. Other drive functions can use
this value through a configuration link.
Parameter Number 325
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
326 CntlNet Input 4
[CntlNet In 4]
CntlNet In 4 contains the fifth word or data group
from the PLC controller output image table. The
ControlNet scanner transfers the data to the drive
every rack scan. The ControlNet Adapter Board can
use this value directly. Other drive functions can use
this value through a configuration link.
Parameter Number 326
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
327 CntlNet Input 5
[CntlNet In 5]
CntlNet In 5 contains the sixth word or data group
from the PLC controller output image table. The
ControlNet scanner transfers the data to the drive
every rack scan. The ControlNet Adapter Board can
use this value directly. Other drive functions can use
this value through a configuration link.
Parameter Number 327
Parameter Type Read Only, Source
Display Units / Drive Units None
Factory Default None
Minimum Value –32767
Maximum Value +32767
File – Group Communications I/O – Channel A
