6–9 Parameters
Publication 1336 FORCE–5.18 ––March, 1999
File 4 – Diagnostics
➀
Monitor Testpoints Fault Sel/Sts Motor Overload
Filt Vel Fdbk 269 Vel Fdbk TP Sel 145 SP Fault Sts 442 Mtr Overload Lim 92
Scaled Vel Fdbk 147 Vel Fdbk TP Low 143 SP Warn Sts 443 Mtr Overld Spd 1 95
Int Torque Ref 167 Vel Fdbk TP Hi 144 SP Fault Sel 440 Mtr Overld Spd 2 96
Internal Iq Ref 168 Vel Reg TP Sel 137 SP Warn Sel 441 Min Overload Lmt 97
Computed Power 182 Vel Reg TP Low 135 ICN Flt Sel 425 Service Factor 94
DC Bus Voltage 268 Vel Reg TP Hi 136 ICN Warn Sel 426
Motor Volt Fdbk 265 Vel Ref TP Sel 110 CP Flt Status 82
Motor Curr Fdbk 264 Vel Ref TP Low 108 VP Flt Status 83
Freq Command 266 Vel Ref TP Hi 109 CP Warn Status 84
Inv Temp Fdbk 270 Auto Tune TP Sel 48 VP Warn Status 85
Torq Mode Stat 184 Auto Tune TP 47 CP Fault Select 86
Lim Motor Flux 271 Logic Tstpt Sel 71 CP Warn Select 87
Enc Pos Fdbk Low 148 Logic Tstpt Data 70 VP Fault Select 88
Enc Pos Fdbk Hi 149 Fault TP Sel 99 VP Warn Select 89
MCB Counter 8 Fault TP 98 Ncfg Flt Status 81
Torq Ref TP Sel 173 PwrUp Flt Status 80
Torque Ref TP 172 Max DB Power 77
Torq TP Sel 1 273 Max DB Temp 78
Torq TP Data 1 274 DB Time Const 79
NOT USED 427
NOT USED 430
NOT USED 431
NOT USED 436
NOT USED 437
NOT USED 439
➀
Descriptions of the shaded parameters are located in the 1336 FORCE user manual.
