Wiring 3-13
Standard Controller Wiring
Diagrams Figure 3.11 through Figure 3.22 show typical wiring for the
SMC-Flex controller.
Figure 3.11 Typical Wiring Diagram for Standard Controller
➀ Customer supplied.
➁ Refer to the controller nameplate to verify the rating of the control power input voltage.
For units rated 625…1250 A, terminals 11 & 12 are factory pre-wired from terminal block
CP1 - terminals 1 & 4.
11 12 13 14 15 16 17 18 19 20 21
23 24 25 26 27 28 29 30 31 32 33
22
34
Stop
Start
L1/1
L3/5
L2/3
T3/6
T2/4
T1/2
M
3-Phase
Input Power
Branch
Protection
SMC-Flex
Controller
Aux #3 Aux #2 Aux #4
Aux #1
SMC-Flex
Control Terminals
PTC
Input
TACH
Input
Ground
Fault
➀
➀
➀
➀
➀
➀
➁
➀
