Communications 7-3
The control panel provides the operator interface to the controller.
All other controls available with the various human interface modules
are non-functional with the SMC-Flex controller.
Start
The green start button, when pressed, will begin motor
operation. (Proper setup of the HIM port is required.)
Stop
The red stop button, when pressed, will halt motor
operation and/or reset a fault.
Jog
The jog button is active only when a control option is
present. Pressing the jog button will initiate the option
maneuver (for example: Pump Stop).
I
O
Jog
ATTENTION
!
The Bulletin 20-HIM interface module’s stop push
button is not intended to be used as an emergency
stop. Refer to the applicable standards for
emergency stop requirements.
ATTENTION
!
The external HIM has a similar programming
operation to the built-in programmer, but note that
differences do exist.
