B-2 Parameter Information
Basic Set
Up
SMC Option 14
Standard
Brake
Pump Control
This a “read-only” parameter that identifies to
the user the type of control module installed.
Basic Set
Up
Motor
Connection
15 Line/Delta Line
This parameter allows the user the ability to
select the power wiring configuration of the
attached motor (WYE or DELTA). A fault
controlled means of disconnecting the line
should always be use in the DELTA mode.
Basic Set
Up
Line Voltage 16 Volt 0…10000 480
This parameter sets the base voltage for the
under / over voltage protective features. For
medium voltage applications the controller
has internal capabilities set of multipliers that
correspond to the line voltage dividers.
Basic Set
Up
Starting Mode 17
Full Voltage
Current Limit
Soft Start
Linear Speed
Pump Start
Soft Start
Allows the user to select the type of start
provided with controller configuration.
Basic Set
Up
Ramp Time 18 Secs 0…30 10
Allows the user to program the time (0…30 s)
that the controller performs the starting
maneuver. The starting maneuver will
automatically transition to bypass and full
voltage if the controller senses that the motor
has reached full speed prior to the ramp time
completion. Also refer to Parameter 129.
Basic Set
Up
Initial Torque 19 %LRT 0…90 70
When using the soft start mode, this
parameter allows the user to adjust the initial
torque level applied to the motor at the
beginning of the start maneuver.
Basic Set
Up
Cur Limit Start
Level
20 %FLC 50…600 350
When using the current limit starting mode,
this parameter allows the user to adjust the
current level applied to the motor during the
start maneuver.
Basic Set
Up
Reserved 21 Reserved
Basic Set
Up
Kickstart Time 22 Secs 0.0…2.0 0.0
When programmed with a non-zero value,
this parameter provides a torque pulse for the
programmed time period at the beginning of
the starting maneuver (0.0…2.0 s).
Basic Set
Up
Kickstart Level 23 %LRT 0…90 0
When the Kickstart Time is programmed, this
parameter provides the user with the ability to
set the level of the torque pulse applied to the
motor (approx. 0…90%).
Basic Set
Up
Option Input 2 24
Disable
Preset Slow Speed
Dual Ramp
Fault
Fault NC
Network
Clear Fault
Disable
Provides the user with the ability to define the
function of option Input #2 (disable, coast,
stop option, fault, fault N.C., network).
Table B.1 Parameter List (Continued)
Group
Parameter
Name
Parameter
Number
Units
Min./
Max.
Default
Settings
Parameter Description
User
Settings
➀ Devices rated 625…1250 Amps, are only programmable to the whole digit ampere. There are no decimal points for any current based parameters.
