Parameter Information
B-3
Dual
Ramp
Starting Mode 2
25
Full Voltage
Current Limit
Soft Start
Linear Speed
Pump Start
Soft Start
When the dual ramp mode is selected, this
parameter allows the user to select the type
of ramp mode used for the second ramp
profile.
Dual
Ramp
Ramp Time 2
26
Secs
0…30
10
When the dual ramp mode is selected, this
parameter allows the user to program the
time (0…30 s) that the controller performs
the starting maneuver for profile #2. Also refer
to Parameter 130.
Dual
Ramp
Initial Torque 2
27
%LRT
0…90
70
When using the soft start mode for profile #2,
this parameter allows the user to adjust the
initial torque level applied to the motor at the
beginning of the start maneuver.
Dual
Ramp
Cur Limit Level 2
28
%FLC
50…600
350
When using the current limit starting mode for
profile #2, this parameter allows the user to
adjust the current level applied to the motor
during the start maneuver.
Dual
Ramp
Reserved
29
Reserved
Dual
Ramp
Kickstart Time 2
30
Secs
0.0…2.0
0.0
This parameter provides a torque pulse for the
programmed time period at the beginning of
the starting maneuver for ramp profile #2.
Dual
Ramp
Kickstart Level2
31
%LRT
0…90
0
This parameter provides the user with the
ability to set the level of the torque pulse
applied to the motor (approx. 0 to 90%) for
ramp profile #2
Basic Set
Up
Stop Mode
32
Soft Stop
Linear Speed
SMB
Accu-Stop
Soft Stop
Allows the user to select the type of stop
provided with the installed controller.
Basic Set
Up
Stop Time
33
Secs
0…120
0
Allows the user to select the length of
stopping time when a stopping mode is
selected.
Linear List
Pump Pedestal
34
(Only available with Pump Control option)
Allows the ability to manually adjust the pump
algorithm slightly for different applications.
The purpose of this parameter is to allow the
pump stop algorithm to be more aggressive
earlier in the ramp. If experiencing overload
trips during stopping, either reduce the
stopping time or try increasing this by units of
5. Try not to exceed a value of 40.
Table B.1 Parameter List (Continued)
Group
Parameter
Name
Parameter
Number
Units
Min./
Max.
Default
Settings
Parameter Description
User
Settings
➁
The 625, 780, 970, and 1250 A units the min./max. is 5.0.…25 and the default value is 5.0 Amps.
