A-8 Specifications
Enclosed Type Line-Connected Controllers, Continued
➀ Use this row for 460V -58 and 575V -59.
➁ Use this row for 460V -59 and 575V -60 and -61.
➂ 970…1250 rated devices are only available as Type 1 and require a door-mounted fan, capable of
delivering 240 cfm.
④ Enclosed 970…1250 rated devices are only avaiable through the modified standards program.
Consult your local Rockwell Automation sales office or Allen-Bradley distributor.
Controller
Rating (A)
IP65 (Type 4/12)
Disconnect Rating
(A)
B Height A Width C Depth
Combination Controllers with Fusible Disconnect
5 30 A/J 610 (24) 406 (16) 254 (10)
25 30 A/J 610 (24) 406 (16) 254 (10)
43 60 A/J 610 (24) 406 (16) 254 (10)
60 100 A/J 610 (24) 406 (16) 254 (10)
85 100 A/J 610 (24) 406 (16) 254 (10)
108 200 A/J 965 (38) 762 (30) 356 (14)
135 200 A/J 965 (38) 762 (30) 356 (14)
201 400 A/J 965 (38) 762 (30) 356 (14)
251 400 A/J 965 (38) 762 (30) 356 (14)
317 600 A/J 1524 (60) 965 (38) 356 (14)
361 600 A/J 1524 (60) 965 (38) 356 (14)
480 ➀ 600 A/J 1524 (60) 965 (38) 356 (14)
480 ➁ 800 A/J 2286 (90) 508 (20) 508 (20)
625 — 2286 (90) 1387 (55) 508 (20)
780 — 2286 (90) 1387 (55) 508 (20)
970 ➂④ — 2286 (90) 1651 (65) 508 (20)
1250 ➂④ — 2286 (90) 1651 (65) 508 (20)
Combination Controllers with Circuit Breaker
5 15 A 610 (24) 406 (16) 254 (10)
25 30 A 610 (24) 406 (16) 254 (10)
43 80 A 610 (24) 406 (16) 254 (10)
60 100 A 610 (24) 406 (16) 254 (10)
85 125 A 610 (24) 406 (16) 254 (10)
108 175 A/175 A Plug 965 (38) 762 (30) 356 (14)
135 225 A/225 A Plug 965 (38) 762 (30) 356 (14)
201 300 A/300 A Plug 965 (38) 762 (30) 356 (14)
251 400 A/400 A Plug 965 (38) 762 (30) 356 (14)
317 600 A/600 A Plug 1295 (51) 914 (36) 356 (14)
361 600 A/600 A Plug 1295 (51) 914 (36) 356 (14)
480 800 A/800 A Plug 1295 (51) 914 (36) 356 (14)
625 — 2286 (90) 1397 (55) 508 (20)
780 — 2286 (90) 1397 (55) 508 (20)
970 ➂④ — 2286 (90) 1651 (65) 508 (20)
1250 ➂④ — 2286 (90) 1651 (65) 508 (20)
