Enclosures
The open-style design of the SMC-Flex controller requires that it be
installed in an enclosure. The internal temperature of the enclosure
must be kept within the range of 0…50°C.
For Type 12 (IP54) enclosures, the following guidelines are
recommended to limit the maximum controller ambient temperature.
There should be a clearance of at least 15 cm (6 in.) above and below
the controller. This area allows air to flow through the heatsink.
Table 2.B Minimum Enclosure Size ➊
➊
Larger enclosure may be required based on options selected. Consult your local Rockwell
Automation Sales office or Allen-Bradley distributor.
➋
Use this row for 460V -58 and 575V -59.
➌
Use this row for 460V -59 and 575V -60 and -61.
Controller
Rating (A)
IP65 (Type 4/12)
B Height
A Width
C Depth
Non-Combination Controller [mm (in.)]
5
610 (24)
406 (16)
254 (10)
25
610 (24)
406 (16)
254 (10)
43
610 (24)
406 (16)
254 (10)
60
610 (24)
406 (16)
254 (10)
85
610 (24)
406 (16)
254 (10)
108
762 (30)
610 (24)
305 (12)
135
762 (30)
610 (24)
305 (12)
201
965 (38)
762 (30)
356 (14)
251
965 (38)
762 (30)
356 (14)
317
1295 (51)
914 (36)
356 (14)
361
1295 (51)
914 (36)
356 (14)
480
1295 (51)
914 (36)
356 (14)
625
2286 (90)
889 (35)
508 (20)
780
2286 (90)
889 (35)
508 (20)
Combination Controllers with Fusible Disconnect
5
610 (24)
406 (16)
254 (10)
25
610 (24)
406 (16)
254 (10)
43
610 (24)
406 (16)
254 (10)
60
610 (24)
406 (16)
254 (10)
85
610 (24)
406 (16)
254 (10)
108
965 (38)
762 (30)
356 (14)
135
965 (38)
762 (30)
356 (14)
201
965 (38)
762 (30)
356 (14)
251
965 (38)
762 (30)
356 (14)
317
1524 (60)
965 (38)
356 (14)
361
1524 (60)
965 (38)
356 (14)
480 ➊
1524 (60)
965 (38)
356 (14)
480 ➋
2286 (90)
889 (35)
508 (20)
625
2286 (90)
1397 (55)
508 (20)
780
2286 (90)
1397 (55)
508 (20)
Combination Controllers with Circuit Breaker
5
610 (24)
406 (16)
254 (10)
25
610 (24)
406 (16)
254 (10)
43
610 (24)
406 (16)
254 (10)
60
610 (24)
406 (16)
254 (10)
85
610 (24)
406 (16)
254 (10)
108
965 (38)
762 (30)
356 (14)
135
965 (38)
762 (30)
356 (14)
201
965 (38)
762 (30)
356 (14)
251
965 (38)
762 (30)
356 (14)
317
1295 (51)
914 (36)
356 (14)
361
1295 (51)
914 (36)
356 (14)
480
1295 (51)
914 (36)
356 (14)
625
2286 (90)
1397 (55)
508 (20)
780
2286 (90)
1397 (55)
508 (20)
