A-2 Specifications
Electrical Ratings
➀ 690V power is only available with 100…240V control .
Device Rating UL/CSA/NEMA IEC
Power Circuit
Rated Operation Voltage
480V
200…480V AC
(–15%, +10%)
200…415V
600V
200…600V AC
(–15%, +10%)
200…500V
690V
230…600V AC
(–15%, +10%)
230…690V/Y
(–15%, +10%)
Rated Insulation Voltage
480V
N/A
500V
600V 500V
690V 690V
Rated Impulse Voltage
480V
N/A 6000V 600V
690V
Dielectric Withstand
480V
2200V AC 2500V 600V
690V
Repetitive Peak Inverse
Voltage Rating
480V 1400V
600V 1600V
690V 1800V
Operating Frequency All 47…63 Hz
Utilization Category
5…480 A MG 1 AC-53B: 3.0-50:1750
625…1250 A MG 1 AC-53B: 3.0-50:3550
Protection Against Electrical
Shock
5…85 A
N/A
IP20
108…480 A
IP2X (with terminal
covers)
625…1250 A IP00 (open Device)
DV/DT Protection
480V & 600V RC Snubber Network
690V None
Transient Protection
480V & 600V Metal Oxide Varistors: 220 Joules
690V None
Control Circuit
Rated Operation Voltage ➀
5…480 A 100…240V AC or 24V AC/DC
625…1250 A 110/120V AC and 230/240V AC
Rated Insulation Voltage All N/A 240V
Rated Impulse Voltage All N/A 3000V
Dielectric Withstand All 1600V AC 2000V
Operating Frequency All 47…63 Hz
Input on-state voltage minimum 85V AC, 19.2V DC / 20.4V AC
Input on-state current
20 mA @120V AC/
40 mA @ 240V AC, 7.6 mA @ 24V AC/DC
Input off-state voltage maximum 50V AC, 10V DC / 12V AC
Input off-state current @ input off-state
voltage
<10 mA AC, <3 mA DC
