3-8 Wiring
Figure 3.6 230V Control Undervoltage Relay Settings for 625…1250 A
Devices
S EE NAMEPLATE FOR S TATU S
LED
240
20 8
220
PICK-UP
% NOMINAL
VOLTAGE
NOMINAL
VOLTAGE
8 5%
115%
DROP OUT
% PICK-UP
0%
95%
10
0.1
S EC.
TIME DELAY
PICK-UP
10
0.1
S EC.
TIME DELAY
DROP-OUT
GENERAL NOTES:
1. SET ALL RELAY POTENTIOMETERS PER ILLUSTRATION.
