20-COMM-D DeviceNet Adapter User Manual
Publication 20COMM-UM002G-EN-P
Appendix
E
Master-Slave I/O Configuration
This appendix lists possible I/O configurations with corresponding M-S
Input and M-S Output parameter settings, and the required data size
allocations for all data exchange methods except Polled. The required data
size allocation tables for the Polled data exchange method are listed below.
M-S Input Parameter
Configurations
Parameter 25 - [M-S Input] has the following five configurable bits.
Figure E.1 Parameter 25 - [M-S Input] Bits and Corresponding I/O
When you enable Cmd/Ref or Datalink in the adapter, you must set the
corresponding bit in Parameter 25 - [M-S Input] if you want the input data
to come from the scanner or master device.
Table E.A
and
Table E.B
list possible configurations for Parameter 25 -
[M-S Input] and the possible data size allocation associated with each
value depending on the data exchange method.
Polled Data Exchange Method Tables
Controller
, or
ControlLogix
, or
PLC-5
,
SLC 500
Table E.A Host Products with 16-bit Reference/Feedback and Datalinks
M-S Input
M-S Output
Allocation (Number of Bytes)
Data Size sent from the Controller to the Adapter
Poll Only
COS Only
Cyclic Only Poll & COS Poll & Cyclic
00000
xxxx0
0
00001
xxxx0
4
00010
xxxx0
4
00011
xxxx0
8
00100
xxxx0
4
00101
xxxx0
8
00110
xxxx0
8
00111
xxxx0
12
01000
xxxx0
4
01001
xxxx0
8
01010
xxxx0
8
xxx0 0000
Datalink D
Datalink C
Datalink B
Datalink A
Cmd/Ref
0 = Peer or other input
1 = Master-Slave input
