C-12
DeviceNet Objects
20-COMM-D DeviceNet Adapter User Manual
Publication 20COMM-UM002G-EN-P
Instance Attributes
6
Get
Status Text
STRING[12]
Text describing the status of the device.
7
Get
Configuration Code
BYTE
Identification of variations.
8
Get
Configuration Text
STRING[16]
Text identifying a variation of a family device.
9
Get
Brand Code
WORD
0x0001 = Allen-Bradley
11
Get
NVS Checksum
WORD
Checksum of the Nonvolatile Storage in a device.
12
Get
Class Revision
WORD
2 = DPI
13
Get
Character Set Code
BYTE
0 = SCANport HIM
1 = ISO 8859-1 (Latin 1)
2 = ISO 8859-2 (Latin 2)
3 = ISO 8859-3 (Latin 3)
4 = ISO 8859-4 (Latin 4)
5 = ISO 8859-5 (Cyrillic)
6 = ISO 8859-6 (Arabic)
7 = ISO 8859-7 (Greek)
8 = ISO 8859-8 (Hebrew)
9 = ISO 8859-9 (Turkish)
10 = ISO 8859-10 (Nordic)
255 = ISO 10646 (Unicode)
15
Get
Languages Supported
STRUCT of:
BYTE
BYTE[n]
Number of Languages
Language Codes (see Class Attribute 2)
16
Get
Date of Manufacture
STRUCT of:
WORD
BYTE
BYTE
Year
Month
Day
17
Get
Product Revision
STRUCT of:
BYTE
BYTE
Major Firmware Release
Minor Firmware Release
18
Get
Serial Number
DWORD
Value between 0x00 and 0xFFFFFFFF
19
Set
Language Selected
BYTE
0 = Default (HIM will prompt at start up)
1 = Language was selected (no prompt)
20
Set
Customer-Generated Firmware
STRING[36]
GUID (Globally Unique Identifier) identifying customer
firmware flashed into the device.
128
Get
Customization Code
WORD
Code identifying the customized device.
129
Get
Customization Revision Number WORD
Revision of the customized device.
130
Get
Customization Device Text
STRING[32]
Text identifying the customized device.
Attribute ID Access Rule Name
Data Type
Description
Attribute ID Access Rule Name
Data Type
Description
3
Get
Component Name
STRING[32]
Name of the component
4
Get
Component Firmware Revision
STRUCT of:
BYTE
BYTE
Major Revision
Minor Revision
5
Get
Component Hardware Change Number BYTE
0 = Not available
8
Get
Component Serial Number
DWORD
Value between 0x00 and 0xFFFFFFFF
