Rockwell Automation 5730 DriveLogix5730 Controller for PowerFlex 700S Drives with Phase II Control User Manual
Page 97
Communicating with Devices on a Serial Link
5-5
Configuring the Communication Driver
Use RSLinx software to configure the serial communication driver. Select
the “DF1” driver.
1.
In the Communications menu, select the Configure Driver.
From the Available Driver Type list select the DF1 Driver, then click
Configure.
2.
Specify a name for the driver and click OK.
ahw0481
.tif
ahw0482.tif
ahw0484.tif
3.
Specify the appropriate communication settings.
ahw0
483.tif
