PowerFlex 700L Frame 1X Drive Installation Instructions – Publication 20L-IN013A-EN-P – June 2009
55
Appendix
Specifications
Category Specification
Agency
Certification Listed to UL508C and CAN/CSA-C2.2 No. 14-M91.
Marked for all applicable European Directives
EMC Directive (2004/108/EC)
EN 61800-3 Adjustable Speed electrical power drive systems
Low Voltage Directive (2006/95/EC)
EN 50178 Electronic Equipment for use in Power Installations
The drive is also designed to meet the following specifications:
NFPA 70 - US National Electrical Code
NEMA ICS 3.1 - Safety Standards for Construction and Guide for Selection,
Installation and Operation of Adjustable Speed Drive Systems.
IEC 146 - International Electrical Code
Category Specification
Protection 400V 480V
AC Input Overvoltage Trip: 528V AC 528V AC
AC Input Undervoltage Trip: 340V AC 340V AC
Bus Overvoltage Trip: 815V DC 815V DC
Bus Undervoltage Shutoff/Fault: 300V DC 300V DC
Nominal Bus Voltage: 600V DC 700V DC
Heat Sink Thermistor: Monitored by microprocessor overtemp trip
Drive Overcurrent Trip
Software Overcurrent Trip:
Hardware Overcurrent Trip: 200% of rated current (typical)
220…300% of rated current (depending on drive
rating)
Line Transients: Up to 6000 volts peak per IEEE C62.41-1991
Control Logic Noise Immunity: Showering arc transients up to 1500V peak
Power Ride-Thru 15 milliseconds at full load
Logic Control Ride-Thru: 0.5 seconds minimum, 2 seconds typical
Ground Fault Trip: Phase-to-ground on drive output
Short Circuit Trip: Phase-to-phase on drive output
Intermittent Overload 110% overload capability for up to 1 minute.
150% overload capability for up to 3 seconds.
Current Limit Capability Proactive Current Limit programmable from
20…160% of rated output current. Independently
programmable proportional and integral gain.
Electronic Motor Overload
Protection Class 10 protection with speed sensitive response.
Investigated by U.L. to comply with N.E.C. Article
430. U.L. File E59272, volume 12.
Environment Altitude: 1000 m (3280 ft) maximum without derating. See
Derate Guidelines on page 58 for operation above
1000 m (3280 ft).
Ambient Operating Temperature
w/o Derating:
IP20, NEMA 1: -10…60 °C (14…140 °F)
Storage Temperature
(all constructions):
-40…70 °C (-40…158 °F)
Atmosphere: Important: Drive must not be installed in an area
where the ambient atmosphere contains volatile or
corrosive gas, vapors or dust. If the drive is not
going to be installed for a period of time, it must be
stored in an area where it will not be exposed to a
corrosive atmosphere.
