PowerFlex 700L Frame 1X Drive Installation Instructions – Publication 20L-IN013A-EN-P – June 2009
54
648 Gearbox Limit Oil Well Pump
650 Adj Volt Phase Adjust Voltage
651 Adj Volt Select Adjust Voltage
652 Adj Volt Ref Hi Adjust Voltage
653 Adj Volt Ref Lo Adjust Voltage
654…660 Adj Volt Preset1-7 Adjust Voltage
661 Min Adj Voltage Adjust Voltage
662 Adj Volt Command Adjust Voltage
663 MOP Adj VoltRate Adjust Voltage
669 Adj Volt TrimSel Adjust Voltage
670 Adj Volt Trim Hi Adjust Voltage
671 Adj Volt Trim Lo Adjust Voltage
672 Adj Volt Trim % Adjust Voltage
675 Adj Volt AccTime Adjust Voltage
676 Adj Volt DecTime Adjust Voltage
677 Adj Volt S Curve Adjust Voltage
700 Pos/Spd Prof Sts ProfSetup/Status
701 Units Traveled ProfSetup/Status
702 Home Position 6.x ProfSetup/Status
705 Pos/Spd Prof Cmd ProfSetup/Status
707 Encoder Pos Tol ProfSetup/Status
708 Counts Per Unit ProfSetup/Status
711 Vel Override ProfSetup/Status
713 Find Home Speed ProfSetup/Status
714 Find Home Ramp ProfSetup/Status
718 Pos Reg Filter ProfSetup/Status
719 Pos Reg Gain ProfSetup/Status
720, 730, 740, 750,
760, 770, 780, 790,
800, 810, 820, 830,
840, 850, 860, 870 Step x Type Profile Setup
Number Parameter Name Group
* These parameters will only be displayed when parameter 053 [Motor Cntl Sel]
is set to option “2” or “3.”
** These parameters will only be displayed when parameter 053 [Motor Cntl Sel]
is set to option “4.”
6.x Firmware 6.002 and later.
721, 731, 741, 751,
761, 771, 781, 791,
801, 811, 821, 831,
841, 851, 861, 871 Step x Velocity Profile Setup
722, 732, 742, 752,
762, 772, 782, 792,
802, 812, 822, 832,
842, 852, 862, 872 Step x AccelTime Profile Setup
723, 733, 743, 753,
763, 773, 783, 793,
803, 813, 823, 833,
843, 853, 863, 873 Step x DecelTime Profile Setup
724, 734, 744, 754,
764, 774, 784, 794,
804, 814, 824, 834,
844, 854, 864, 874 Step x Value Profile Setup
725, 735, 745, 755,
765, 775, 785, 795,
805, 815, 825, 835,
845, 855, 865, 875 Step x Dwell Profile Setup
726, 736, 746, 756,
766, 776, 786, 796,
806, 816, 826, 836,
846, 856, 866, 876 Step x Batch Profile Setup
727, 737, 747, 757,
767, 777, 787, 797,
807, 817, 827, 837,
847, 857, 867, 877 Step x Next Profile Setup
Number Parameter Name Group
