PowerFlex 700L Frame 1X Drive Installation Instructions – Publication 20L-IN013A-EN-P – June 2009
3
Each PowerFlex 700L Frame 1X drive can be identified by its catalog
number, which is CNMD180W0ENNNC1. The catalog number is on the
shipping label and drive data nameplate. The catalog number includes the
drive and any factory-installed options.
Qualified Personnel
Personal Safety
Product Safety
Catalog Number Explanation
Step 1 Read the Precautions and General Information
!
ATTENTION: Only qualified personnel familiar with adjustable frequency AC drives and
associated machinery should plan or implement the installation, start-up and subsequent
maintenance of the system. Failure to comply may result in personal injury and/or equipment
damage.
!
ATTENTION: To avoid an electric shock hazard, verify that the voltage on the bus capacitors has
discharged before performing any work on the drive. Measure the DC bus voltage at the DC+ and
DC– Test Pt. sockets on the drive (see item 9 in
Figure 1 on page 8 for location). The voltage must
be zero.
!
ATTENTION: Risk of injury or equipment damage exists. DPI or SCANport host products must
not be directly connected together via 1202 cables. Unpredictable behavior can result if two or more
devices are connected in this manner.
!
ATTENTION: The drive start/stop/enable control circuitry includes solid state components. If
hazards due to accidental contact with moving machinery or unintentional flow of liquid, gas or
solids exist, an additional hardwired stop circuit may be required to remove the AC line to the drive.
An auxiliary braking method may be required.
!
ATTENTION: Loss of control in suspended load applications can cause personal injury and/or
equipment damage. Loads must always be controlled by the drive or a mechanical brake. Parameters
600…611 are designed for lifting/torque proving applications. It is the responsibility of the engineer
and/or end user to configure drive parameters, test any lifting functionality and meet safety
requirements in accordance with all applicable codes and standards.
!
ATTENTION: An incorrectly applied or installed drive can result in component damage or a
reduction in product life. Wiring or application errors, such as, undersizing the motor, incorrect or
inadequate AC supply, or excessive ambient temperatures may result in malfunction of the system.
!
ATTENTION: This drive contains ESD (Electrostatic Discharge) sensitive parts and assemblies.
Static control precautions are required when installing, testing, servicing or repairing this assembly.
Component damage may result if ESD control procedures are not followed. If you are not familiar
with static control procedures, reference Guarding Against Electrostatic Damage, publication
8000-4.5.2 or any other applicable ESD protection handbook.
