Appendix
A
Specifications
This appendix provides the specifications for the HIM.
Communications
Electrical
Mechanical
Environmental
Topic Page
Communications 65
Electrical 65
Mechanical 65
Environmental 65
Regulatory Compliance 66
Protocol Drive Peripheral Interface (DPI)
Data Rates 125 kbps or 500 kbps
Consumption 140 mA at 12V DC supplied by the Host Drive
Dimensions
Height
Width
Depth
20-HIM-A6 20-HIM-C6S
116.0 mm (4.57 in.) 180.0 mm (7.08 in.)
70.0 mm (2.75 in.) 93.0 mm (3.66 in.)
16.0 mm (0.63 in.) 25.0 mm (0.98 in.)
Weight 91 g (3.2 oz.) 173 g (5.7 oz.)
Temperature
Operating
Storage 0…50 °C (32…122 °F)
-40…85 °C (-40…185 °F)
Relative Humidity 5…95% non-condensing
Atmosphere Important: The HIM must not be installed in an area where the ambient atmosphere
contains volatile or corrosive gas, vapors or dust. If the HIM is not going to be installed for
a period of time, it must be stored in an area where it will not be exposed to a corrosive
atmosphere.
Vibration
Operating
Non-Operating 2.5 g @ 5 Hz…2 kHz
5 g @ 5 Hz…2 kHz
Shock
Operating
Non-Operating 30 g peak acceleration, 11 (±1) ms pulse width
50 g peak acceleration, 11 (±1) ms pulse width
