Rockwell Automation Publication 20HIM-UM001D-EN-P - February 2013
11
Chapter
1
Getting Started
The PowerFlex 20-HIM-A6 and 20-HIM-C6S HIMs provide a communication
interface to configure and monitor PowerFlex 753 and PowerFlex 755 AC drives
and their connected peripherals. These HIMs are also backward compatible with
all PowerFlex 7-Class drives, but with limited functionality.
HIM Types
At the time of publication, the following enhanced PowerFlex 7-Class HIMs are
available.
Features
The enhanced PowerFlex 20-HIM-A6 and 20-HIM-C6S HIMs provide the
following benefits over the more basic PowerFlex 7-Class HIMs (catalog
numbers 20-HIM-A3, 20-HIM-A5, 20-HIM-C3S, and 20-HIM-C5S):
•
Full-numeric keypad with fully-integrated navigation capability to more
easily configure and monitor the drive and its connected peripherals.
•
Better keypad touch response and improved tactile feel to provide more
gratifying, error-free data entry.
•
More intuitive access and new menu structures that increase HIM
operating efficiency.
•
Simplified custom name assignments for drive/peripherals (for example,
Pump 1) to reduce required key presses.
Topic
Page
HIM Catalog Number
Description
20-HIM-A6
(1)
(1) Supports English, Portuguese, French, Italian, German, Spanish, and Dutch
languages. The HIM firmware can be updated in the field to support other available
languages. Important: The language selected for download at the Rockwell
Automation Web Updates website a
will replace all other supported languages—except English, which will
always remain as the default language.
NEMA Type 1 HIM
20-HIM-C6S
(1)
Remote-Mount NEMA Type 4X/12 HIM
