Chapter 2, Installing the him – Rockwell Automation 20-HIM-C6S PowerFlex (Human Interface Module) User Manual
Page 13
Rockwell Automation Publication 20HIM-UM001D-EN-P - February 2013
13
Chapter
2
Installing the HIM
This chapter provides instructions for installing and removing the HIM.
There are two types of enhanced PowerFlex 7-Class HIM:
•
NEMA Type 1 (catalog number 20-HIM-A6)
•
Remote-mount NEMA Type 4X/12 (catalog number 20-HIM-C6S),
which also includes a 1202-C30 interface cable for connection to the drive
Topic
Page
20-HIM-A6 HIM
20-HIM-C6S HIM
