17.2.18

LS_ParFree_b

This system block outputs 16 parameterisable digital signals.

Outputs

Parameter

Identifier

Data type

Value/meaning

bPar1 ... bPar16

BOOL

Output of the signal levels (FALSE/TRUE) parameterised in

C00470/1...16

Parameter

Possible settings

Info

C00470/1...16

Selection of signal levels to be output

• Bit 0 ... 15 = bPar1 ... bPar16

0 "FALSE" signal is output
1 "TRUE" signal is output
