7.2.3 Terminal assignment of the control modes
The following comparison provides information about which inputs/outputs of the application block LA_NCtrl are interconnected to the digital
and analog input/output terminals of the drive controller in the different control modes.
Control mode ( C00007 )
10: Terminals 0 12: Terminals 2 14: Terminals 11 16: Terminal 16 20: Keypad 21: PC 30: CAN 40: MCI
Digital input terminals
RFR
Controller enable / Reset of error message
bFailReset
(In case of 8400 protec, the RFR terminal is internally set to HIGH level via wire jumper.)
X41/DI1 Fixed setpoint 1/3
bJogSpeed1
Change of direction of
rotation
bSetSpeedCcw
Fixed setpoint 1/3
bJogSpeed1
- - Quick stop
bSetQuickstop
X41/DI2 Fixed setpoint 2/3
bJogSpeed2
Activate manual DC-
injection braking (DCB)
bSetDCBrake
Fixed setpoint 2/3
bJogSpeed2
- - - -
X42/DI3 Activate manual DC-
injection braking (DCB)
bSetDCBrake
Quick stop
bSetQuickstop
Motor potentiometer:
Increase speed
bMPotUp
CW rotation quick stop
bRLQCw
- - - -
X42/DI4 Change of direction of rotation
bSetSpeedCcw
Motor potentiometer:
Decrease speed
bMPotDown
CCW rotation quick stop
bRLQCcw
- - - -
X43/DI5 - - - - - - - -
X43/DI5 - - - - - - - -
Analog input terminals
X50/A1U
Main speed setpoint
nMainSetValue_a
10 V ≡ 100 % reference speed ( C00011 )
- - Additional speed setpoint
nAuxSetValue_a
10 V ≡ 100 % reference speed ( C00011 )
X50/A1I - - - - - - - -
Digital output terminals
DO1/DO2 is only available after respective change of the function assignment in
C00116 .
X42/DO1 Status "Drive is ready"
bDriveReady
X42/DO2 -
